FMS Model remote control electric aircraft model assembly foam machine fixed wing

Indoor/Outdoor Use: OUTDOOR

Video Capture Resolution: other

Camera Mount Type: other

Takeoff Weight: 1795g

Control Channels: 6 channels

Material: Foam

Flight Time: 5~10

Controller Mode: MODE2

Recommend Age: 14+y

Operator Skill Level: Intermediate, expert

Remote Control: Yes

Package Includes: Original Box

Package Includes: Operating Instructions

State of Assembly: Ready-to-Go

Aerial Photography: No

Certification: CE

Overview:

The original 70mm Viper wasn't always the first choice for novice jet players – but now, she is! FMSRC 15th Anniversary Edition 70mm Viper, here we go! The comment from players that the Viper “does any acrobatic trick you can throw at it" is a true portrayal of the excellent performance of The 70mm Viper. The reason the 15th-anniversary edition of the Viper can give you anything you want is that has made a qualitative improvement on the basis of the previous work.

The full set of CNC machined metal shock-absorbing landing gear (with the upgraded kneeling front landing gear replacing the wire landing gear). Combined with the precise control provided by the digital metal gear servo system and ball joint linkage, the Viper is easy to control throughout the flight, comparable to that of a sports aircraft. The humanized snap-on cockpit design. Airframe with optimized aerodynamic design with longer wings and wingtips that reduce air resistance, making the Viper's posture clearer during flight. Equipped with a high configuration power system: High-speed brushless 3060-KV1900 motor, 70mm 12-blade ducted fan, and precise, high-quality 80A ESC. Provide excellent vertical performance and instantaneous throttle response in flight. Perhaps even more fascinating is the sound the powertrain makes -- it's almost like a real turbine!

Key Features:

High-quality 80A ESC, powerful KV1900 in-runner motor with the latest 70mm 12-blade EDF

A full set of CNC metal shock-absorbing landing gear (A.K.A kneeling nose)

With flaps (servo-installed)

Screw-together construction

Clip-on cockpit design

Pre-installed ball-head joints provide precise surface control

Specification:

Wingspan 1100mm /43.3 in

Overall Length 1025mm / 40.4 in

Flying Weight Around 1795g

Motor Size I3060-KV1900 inner running

ESC 80A (5A BEC)

Servo 9g metal digital servo *8

Radio 6 Channel (not included)

CG (center of gravity) 90-95mm(From Leading Edge)

Ducted Fan Size 70mm 12 blade

Recommended Battery 22.2V 3300mAh 35C(not included)

Aileron Yes

Elevator Yes

Rudder Yes

Flaps Yes

Retracts Yes, retractable main and front gears

Approx. Flying Duration 5 minutes

Minimum Age Recommendation 14+

Experience Level Intermediate

Recommended Environment Outdoor

Assembly Time 10-30 mins

Is Assembly Required Yes

Material Durable EPO Foam

Wing Load 93.5g/dm² ( oz/in²)

Wing Area 19.2 dm² ( sq.in)

Package Options:

PNP (Plug-and-Play) airplanes include the ESC, motor, and servos all pre-installed from the factory. Transmitter, receiver, battery, and charger are not included.
